| Project | Specifications | ||||
| K3P-07AS | K3P-07BS | K3P-07CS | |||
| Control Mode | Loop Calculation Storage Program | ||||
| Programming Language | Statement Table, Ladder Diagram | ||||
| I/O Refresh Mode | I/O Refresh Mode; Perform Scan Cycle Refresh | ||||
| Instructions | The Basic Instructions | 30 | |||
| Application Instructions | 220 | ||||
| The Speed of the Order Processing | The Basic Instructions | 0.5Us/Step | |||
| Program Capacity | 7k Step | ||||
| The Number | P(I/O Relay) | P0000-P015F(512 Points) | |||
| M (Auxiliary Relay) | M0000-M191F(3072 Points) | ||||
| K (Maintenance Relay) | K0000-K031F(1024 Points) | ||||
| L (Connecting Relay) | L0000-L063F(1024 Points) | ||||
| F (Special Relay) | F0000-F063F(1024 Points) | ||||
| T (Timer) | 100MS | T000-T191(192 Points) Can Be Changed According to Parameter Settings | |||
| 10MS | T192-T255(64 Points) Can Be Changed According to Parameter Setting | ||||
| C (Counter) | C000-C255(256 Points) | ||||
| S( Step-by-Step Control) | S00.00-S99.99(100X100 Steps) | ||||
| D (Data Storage) | D0000-D4999 (Step 5000) | ||||
| 5 Types of Timer | Rising Edge, Failling Edge, Accumulative, Monostable, and Complex Trigger Timer | ||||
| Counter 4 Types | Add, Subtract, Add and Subtract, Ring Counter | ||||
| Special Function | Online Editing, I/O Force on/off | ||||
| Operation Mode | Run, Stop, Pause, Debug | ||||
| Most Large Scale | Substrate (Non-Extendable) | ||||
| Self-Diagnosis | Watchdog Timer to Detect Storage Errors and Input and Output Errors | ||||
| Other Features | RS-232C Communication Built-in | RS-422/485 Communication Built-in | RS-232C Communication Built-in | ||
| Internal Current Consumption (Dc5v) | 170mA | 210mA | 170mA | ||
>> Load Module
|
| Type | The DC Input | The AC Input | |||||
| Project |
| G6I-D21A | G6-D22A | G6I-D22B | G6I-D24A | G6I-D24B | G6I-A11A | G6I-A21A |
| Entry Point | 8 dian | 16-Point | 32-Point | 8 dian | ||||
| Rated Input Voltage | DC 12/24V | DC 24V | DC12/24V | DC 24V | AC100-120V | AC200-240V | ||
| Rated Input Current | 3mA/7mA | 7mA | 3mA/7mA | 7mA | 7mA | 11mA | ||
| Voltage and Current | Open | DC9.5V.3.5Ma Or Less | 15V/4.3mA | 9.5V/3.5mA | 15V/4.3mA | AC 80V/5mA | ||
| off | DC below 5V/1.5ma | 5V/1.7mA | 5V1.5mA | 5V/1.7mA | AC 30V/2mA | |||
| The Input Electronic Resistance | 3.3KΩ | 15KΩ | 20KΩ | |||||
| Response Time | Off → Open | 5mS following | 15mS following | |||||
| Open → off | 5mS following | 25mS following | ||||||
| Public Way | 8 dian/1COM | 32-Point/1COM | 8 dian/1COM | |||||
| Type | Common Land, Common Source (Infinite Type) | Common Source (Common) | Common Land, Common Source (Infinite Type) | Common Source (Common) |
| |||
| Isolation Mode | Photoelectric Isolation | |||||||
| Running Index | LED Flickers When Input on | |||||||
| Internal Power Consumption (Dc5v) | 40mA | 70mA | 75mA | 35mA | ||||
>> Output Module
|
| Type | Relay Output | Triac Output | Transistor Output | ||||
| Project |
| G6Q-RY1A | G6Q-RY2A | G6Q-SS1A | G6Q-TR2A | G6Q-TR2B | G6Q-TR4A | G6Q-TR4B |
| Output Points | 8 dian | 16-Point | 8 dian | 16-Point | 8 dian | |||
| Rated Input Voltage | DC 12/24V,AC100-220V | AC100-240V | DC12/24V | |||||
| Rated Input Current | 2a/1 Point | 2a/1 Point, 5A/1com,,, | 1A/1 Point 4A/1COM | 0.5A/1 Point, 4A/1com | 0.1A/1 Point, 2a/1com | |||
| Leakage Current When off | 0.1mS following | 2.5mS following | 0.15mS following | |||||
| Voltage Drop on | - | AC1.5V following | DC1.5 following | DC2.5V following | DC3.0V following | |||
| Response Time | Off → Open | 10mS following | 1mS following | 2mS following | ||||
| Open → off | 12mS following | 0.5cycle + 1mS following | 2mS following | |||||
| Public Way | 1 Point/1COM | 8 dian/1COM | 8 dian/1COM | 16-Point/1COM | 16-Point/1COM | 32-Point/1COM | 32-Point/1COM | |
| Type | - | Common Source (Common) | ||||||
| Isolation Mode | Relay Isolation | Photoelectric Isolation | ||||||
| The Surge Absorption |
| Variable Electronic Resistance Cr Absorber | Diode | |||||
| External Power Supply | - | 24V | ||||||
| Running Index | LED Flickering When Output on | |||||||
| Internal Power Consumption (Dc5v) | 210mA | 400mA | 190mA | 180mA | 170mA | 140mA | 145mA | |
>> Input and Output Hybrid Module
|
| Type | GM6 |
| Type | GM6 | |
| Project |
| G6H-DR2A Input | prefix = v ns = "urn:schemas-microsoft-com:vml"
|
| G6H-DR2A Output | |
| Input Points | 8 dian | Input Points | 8 dian | |||
| Isolation Mode | Photocoupling | Isolation Mode | Relay Isolation | |||
| Rated Input Voltage | DC 12/24V | Rated Input Voltage | DC 12/24V( Electronic Resistance Load)/1 Point, 4A/1com | |||
| Voltage/Current | AC 220v/2a (Cosφ = 1)/1 Point, 4A/1com | |||||
| Rated Input Current | 3/7mA | Zui Small Load Voltage/Current | DC5V/1mA | |||
| The Usage Voltage Range | DC 10.2-28.8V | Zui Large Load Voltage/Current | AC250V,DC125V | |||
| Zui Input Points at the Same Time | Percent yi bai on | Leakage Current When off | 0.1mA(AC220V,60hZ) | |||
| Leakage Current When off | Dc9.5v below/3.5ma above | Zui Large Opening and Closing Frequency | 1200 | |||
| Voltage Drop on | Dc5v above/1.5ma below | The Surge Absorption | No | |||
| The Input Electronic Resistance | 3.3KΩ | Life | Mechanical | G6Q-RY2A Same | ||
| Response Time | Off → Open | 5mS following | Electrical | - | ||
| Open → off | 7mS following | Response Time | Off → Open | 10ms following | ||
|
| - | Open → off | 12ms following | |||
| Public Way | 8 dian/1COM | |||||
| Running Index | LED Flickering When Output on | |||||
| External Connection Mode | 18 O'clock, Inner Terminal Connection (M3x6) | |||||
| Internal Power Consumption | 250mA | |||||
| Weight | 200g | |||||
