SR3B261BD PLC Controller Module,& Have in stock

Zelio Logic

Modular smart relay

With

0...500 with FBD programming
0...240 with ladder programming

6...90 ms

10 yearsat 77 °F (25 °C)

6 s/monthat 77 °F (25 °C)
12 min/yearat 32...131 °F (0...55 °C)

Program memory on each power up

24 V

19.2...30 V

190 mA (without extension)
300 mA (with extensions)

10 W with extensions
6 W without extension

With

16 conforming to EN/IEC 61131-2 type 1

Resistive

24 V DC

4 mA

1 kHzfor discrete input

>= 15 Vfor I1...IA and IH...IR discrete input circuit
>= 15 Vfor IB...IG used as discrete input circuit

<= 5 Vfor I1...IA and IH...IR discrete input circuit
<= 5 Vfor IB...IG used as discrete input circuit

>= 1.2 mA for IB...IG used as discrete input circuit
>= 2.2 mA for I1...IA and IH...IR discrete input circuit

<= 0.5 mA for IB...IG used as discrete input circuit
<= 0.75 mA for I1...IA and IH...IR discrete input circuit

3-wire proximity sensors PNP (discrete input)

6

Common mode

0...10 V
0...24 V

30 V (analogue input circuit)

8 bits

39 mV (analogue input circuit)

Smart relay cycle time analogue input circuit

+/- 5 %at 77 °F (25 °C)for analogue input circuit
+/- 6.2 %at 131 °F (55 °C)for analogue input circuit

+/- 2 %at 131 °F (55 °C)for analogue input circuit

10 m between stations, with screened cable (sensor not isolated) analogue input circuit

12 kOhm (IB...IG used as analogue input circuit)
12 kOhm (IB...IG used as discrete input circuit)
7.4 kOhm (I1...IA and IH...IR discrete input circuit)

10 relay output(s)

24...250 V AC (relay output)
5...30 V DC (relay output)

NO relay output

5 A for 2 outputs (relay output)
8 A for 8 outputs (relay output)

500000 cycles AC-12at 230 V, 1.5 Afor relay output conforming to EN/IEC 60947-5-1
500000 cycles AC-15at 230 V, 0.9 Afor relay output conforming to EN/IEC 60947-5-1
500000 cycles DC-12at 24 V, 1.5 Afor relay output conforming to EN/IEC 60947-5-1
500000 cycles DC-13at 24 V, 0.6 Afor relay output conforming to EN/IEC 60947-5-1

>= 10 mAat 12 V (relay output)

0.1 Hz (at Ie)for relay output
10 Hz (no load)for relay output

10000000 cycles (relay output)

4 kV conforming to EN/IEC 60947-1 and EN/IEC 60664-1

With

10 ms (from state 0 to state 1) relay output
5 ms (from state 1 to state 0) relay output

Screw terminals, clamping capacity: 1 x 0.2...1 x 2.5 mm² AWG 25...AWG 14 semi-solid
Screw terminals, clamping capacity: 1 x 0.2...1 x 2.5 mm² AWG 25...AWG 14 solid
Screw terminals, clamping capacity: 1 x 0.25...1 x 2.5 mm² AWG 24...AWG 14 flexible with cable end
Screw terminals, clamping capacity: 2 x 0.2...2 x 1.5 mm² AWG 24...AWG 16 solid
Screw terminals, clamping capacity: 2 x 0.25...2 x 0.75 mm² AWG 24...AWG 18 flexible with cable end

4.42 lbf.in (0.5 N.m)

III conforming to EN/IEC 60664-1

0.88 lb(US) (0.4 kg)
