Kinco F10 10.1" TFT HMI SCREEN PANEL
HAVE IN STOCK,FASTING SHIPPING
Performance specification
| Display | 10" TFT |
| Resolution | 1280*800 pixels |
| Color | 65536 |
| Backlight | LED |
| Brightness | 250cd/m2 |
| Backlight Life | 50000 Hours |
| Touch Panel | 4-Wire Precision Resistance Network |
| Processor | 800MHz RISC |
| Memory | 128M Flash + 64M SDRAM |
| Recipe Memory & RTC | 512KB + RTC |
| Expandable memory | 1USB HOST |
| Printer Port | Serial Port |
| Ethernet | None |
| Program Download | USB Host |
| COM Port | COM0:PLC RS485-2W;COM2:PC/PLC RS232 |
Electrical Specification
| Isolated power supply | Built-in |
| Rated Power | 8W |
| Rated Voltage | DC24V(In-build isolated powe supply) |
| Input Range | DC18-28V |
| Power Down Allowed | <3ms |
| Insulation Resistance | Greater than 50MΩ@ 500V DC |
| Dielectric Strength Test | 500 VAC 1 Minute |
Environment Specification
| Operating Temperature | 0～50℃ |
| Operating Humidity | 10～90%RH Non-Condensing |
| Storage Temperature | -10～60℃ |
| Storage Humidity | 10～90%RH Non-Condensing |
| Shockproof Test | 10～25Hz (X, Y, Z Direction, 2G, 30 Minutes) |
| Cooling Method | Natural Air Cooling |
Structure Specification
| Shell Color | Metal gray |
| Shell Material | ABS |
| Dimensions(mm) | 250×167×28.4mm |
| Cutout Size(mm) | Standard rack mountig |
| Weight | 0.91 Kg |
Dimensions (Unit:mm)
