| Model | EM222 16 outputs |
| Product Description | 16DO,24V DC;Transistor; Optical isolation with high immunity |
| The bus current consumption | 110mA |
| Power loss | 3W |
| Number of digital outputs | 16 |
| Signal output type· | Transistor |
| Isolation | Optical coupler |
| Rated voltage | 24V DC |
| Permissible voltagerange | 20.4~28.8V DC |
| Rated current | 0.75A |
| Lamp load | 5W |
| Cable Length (Shielded) | 500m |
| Cable Length(unshielded) | 150m |
| Switching frequency | / |
| Lifetime contact mechanical | / |
| Lifetime contactmechanical( rated load voltage) | / |
| Dimensions(W x H x D)(mm) | 71.2×80×62 |
| Order Number | 222-1BH22-0XA0 |
The module made by us, Compatible SIMATIC S7-200 module 100%,
If you have any question, please tell us.
